ISUZU F/FVR Truck Mounted Crane

Wheelbase	5550
Engine	241hp/300hp
Transmission	Fast 8JS95TE-C
Box material	Q235/Q355
Box size	4800X2450X600
Crane brand	XCMG/Palfinger
Crane tonnage	8000 Kg

Inquire Now Next Product

Product Configuration

Components	Truck crane is a kind of equipment that realizes the lifting, rotation and lifting of goods through hydraulic lifting and telescopic system. It mainly consists of four parts: chassis, crane, cargo box and hydraulic system. ‌
Main components	The carriage is made of high-quality steel, with strong rigidity and strength, durable and not easy to deform. The crane is divided into a base and a crane boom. A 360-degree turntable is installed on the base to facilitate the crane to work at any angle. The overall cross subbeam is configured to strengthen the beam strength and the load of the whole vehicle. The front and rear hydraulic legs are designed. The hydraulic system is equipped with a variety of proportional multi-way valves and balance valves to ensure the stability and safety of the body during work.
Durable	The crane is made of high-strength manganese steel, hexagonal working arm, and a single-bar zipper synchronization device. There are a variety of pump bodies built in the crane, and each pump body is connected through a multi-way valve and a balance valve to ensure that the crane works smoothly and stably.
Structural design	Lightweight design of the whole vehicle, modular production, high appearance and value-preserving. Made of high-strength steel, light weight, high strength, stable and reliable.
Vehicle advantages	Unique, the core parts of the synchronous telescopic boom are imported parts, with stable quality. The electronic control system is developed by the original factory, and the dual rotary drive is specially designed for the vehicle, which cooperates with each other to give full play to its comprehensive performance.

Vehicle Diagram

Single cylinder cable synchronization device
Rotating device
Hydraulic outriggers
Control device
Integral cross-beam
Crane boom

Vehicle Diagram

Truck Mounted Crane

Model	Cab type	WB	OAL	OW	OH	FOH	ROH	L	W	H
FVR	row half	5550	9000	2550	3650	1335	2115	4800	2450	600
Note: The above dimensions are for reference only and can be customized as required

Isuzu FVR Truck Crane
Wheelbase	5550
Engine	241hp/300hp
Gearbox	Fast 8JS95TE-C
Box material	Q235/Q355
Box size	4800X2450X600
Crane brand	XCMG /Palfinger
Crane tonnage	8000 Kg
Factory standard	Full rotation, no seat, standard front legs, left and right side protection, rear protection, reflective stickers

Product name			Isuzu FVR Truck-mounted Crane
Vehicle parameters	Vehicle wheelbase (mm)		5550
	Vehicle size()		9000X2550X3650
	Total mass (Kg)		18000
	Curb weight (Kg)		9825
	Number of passengers in the cab		3
	Maximum speed		90
	Tire specifications		295/80R22.5 16PR
	Number of tires		6+1
	Emission standards		National V, National VI
Transmission parameters	Transmission model		Fast 8JS95TE-C
	Gear gear		8Forward +2 Reverse
	6HK1-TCL	177kw/241hp	○
	6HK1-TCH	221kw/300hp	○
	6HK1-TCG60	221kw/300hp	○
	6HK1-TCG61	177kw/241hp	○
Special performance	Box material	Q235	○
		Q355	○
	Box size		4800X2450X600
	Crane brand		XCMG/Palfinger
	Crane tonnage		8000 Kg
	Factory standard		Full rotation , no seat, standard front legs, left and right side protection, rear protection, reflective stickers
Note: Please contact us for confirmation of detailed configuration, Support customization
