ISUZU NKR /100P Dump Truck

Wheelbase	2490mm-3815mm
Drive	4X2/4X4
Engine model	4KH1
Engine horsepower	98HP-130HP
Load	1.5T-4T
Box volume	3m³-5 m³
Box material	Q235/Q355/high-strength steel

Inquire Now Next Product

Product Configuration

Structure	The double-bar middle top structure of the dump truck is adopted, which makes the lifting stable and easy to operate.
Durability	The oil cylinder has strong lifting force, and the lifting durability test reaches 20,000 times without oil leakage
Lifting angle	The lifting angle of the car body of some models can reach 48°, and the lifting and lowering time of the car body is ≤15 seconds, realizing fast and stable unloading.
Parts	The dumping mechanism adopts well-known domestic brands, with high reliability and less maintenance
Box	The entire box is made of high-carbon steel, with strong rigidity and strength, durable and not easy to deform
Professional customization	Seven years of modification experience, free customization of modification plans according to vehicle needs
Vehicle advantages	Isuzu chassis + high-quality dump cargo box + domestic high-quality tilting mechanism are perfectly matched. During the development and design process, the chassis, body, and dumping system are matched and designed according to the whole vehicle concept to give full play to their comprehensive performance, not simply pieced together.

Vehicle Diagram

Lift control valve
Power take-off assembly
Hydraulic cylinder
Side protection
Tianzi grid box
Hydraulic oil tank

Vehicle Diagram

100P Dump Truck

Model	Cab type	WB	OAL	OW	OH	FOH	ROH	L	W	H
100P	Single row	2765	5000	1900	2300	1015	1220	3000	1900	500
	Single row	3360	5600	1950	2300	1015	1225	3800	1900	500
	Single row	3815	6400	1950	2300	1015	1570	4500	1900	500
Note: The above dimensions are for reference and can be customized according to needs

Isuzu 100P dump truck
Wheelbase	2765	3360	3815
Box volume	3 m³	4 m³	5 m³
Cabinet size	3000×1900×500	3800X1900X500	4500×1900×500
Motor	98hp/115hp/120hp/130hp	98hp/115hp/120hp/130hp	98hp/115hp/120hp/130hp
Gearbox	Isuzu MSB	Isuzu MSB	Isuzu MSB

Vehicle parameters	Wheelbase (mm)		2765	3360	3815
	Vehicle size()		5000X1900X2300	5600X1950X2300	6400X1950X2300
	Gross weight (Kg)		4495	4495/7300	7300
	Curb weight (Kg)		2675	3185	3750
	Number of passengers in the cab		2	2	2
	Top speed		98	98	98
	Tire specifications		7.00R16LT 8PR	7.00R16LT 8PR	7.00R16LT 8PR
	Number of tires		6+1	6+1	6+1
	Emission standards		National 5, National 6	National 5, National 6	National 5, National 6
Transformation parameters	Transmission model		Isuzu MSB	Isuzu MSB	Isuzu MSB
	Gear gear		5Forward + 1 Reverse	5Forward + 1 Reverse	5Forward + 1 Reverse
	4KH1CN5LS	72kw/98hp	○	○	○
	4KH1CN5MD	83kw/115hp	○	○	○
	4KH1CN5HD	95kw/130hp	○	○	-
	4KH1CN6LB	88kw/120hp	○	○	○
Dedicated performance	Cabinet material	Q235	○	○	○
		Q345	○	○	○
		High-strength steel	○	○	○
	Lifting method		Parallel bars lift	Parallel bars lift	Parallel bars lift
	Box volume		3 m³	4 m³	5 m³
	Cabinet size		3000×1900×500	3800X1900X500	4500×1900×500
	Factory standards		The bottom plate is 4mm / side plate 3mm, the flip mechanism through the shaft, the integral rear fender is welded on the cargo box, the left and right side protection, the rear protection, and the reflective label	The bottom plate is 4mm / side plate 3mm, the flip mechanism through the shaft, the integral rear fender is welded on the cargo box, the left and right side protection, the rear protection, and the reflective label	The bottom plate is 4mm / side plate 3mm, the flip mechanism through the shaft, the integral rear fender is welded on the cargo box, the left and right side protection, the rear protection, and the reflective label
Note: Please contact us for detailed configuration for confirmation, support customization
