ISUZU NPR EV/EV700 Pallet truck

Vehicle type	EV700 plate truck
wheelbase	3815mm-5200mm
Driving form	TZ370XS-LKM0851
Engine Model	75KW
Engine Horsepower:	6T
Load	106.95kWh
Box volume	300km
Box material	5.3m³-7.2m³

Inquire Now Next Product

Product Configuration

body	The whole body is made of high carbon steel, with strong rigidity and strength, durable, not easy to deformation
sideboard	The left and right side panels are strengthened at a certain distance to improve the overall strength of the side panels
spray	Preferably domestic quality paint, strong adhesion, wear resistance, acid and alkali resistance, good heat resistance.
subframe	Effectively isolate road vibration, improve ride comfort
Professional customization	Seven years of modification experience, according to the needs of the car to customize the modification plan free of charge
Vehicle advantage	Isuzu chassis + quality cargo compartment perfect match. In the process of development and design, according to the vehicle thinking, the chassis, the body, the matching design, give full play to its comprehensive performance, not a simple patchwork.

Vehicle Diagram:

Stiffening beam
Side protection
subframe
Shear plate bending machine
Detachable bars
Spray zone

Vehicle Diagram :

Model	WB	OAL	OW	OH	FOH	ROH	L	W	H
EV700	3360	6200	2400	2380	1110	1730	4200	2300	450
	3815	7000	2400	2380	1110	2075	5100	2300	450
	4175	7600	2400	2380	1110	2315	5600	2300	450
	4475	8050	2400	2380	1110	2465	6100	2300	450
	5200	8950	2400	2380	1110	2640	7000	2300	450
The above sizes are for reference and can be customized according to requirements

Product name			Isuzu EV700 Pallet truck
whole parameter	vehicle wheelbase(㎜)		3815	4175	4475	5200
	Vehicle size()		7000X2400X2380	7600X2400X2380	8050X2400X2380	8950X2400X2380
	Total weight (Kg)		10550	10550	10550	10550
	Curb weight (Kg)		4730	4830	5000	5700
	Number of passengers in the cab		3	3	3	3
	Maximum speed		110	110	110	110
	Tire specifications		235/75R17.5 16PR	235/75R17.5 16PR	235/75R17.5 16PR	235/75R17.5 16PR
	Number of tires		6+1	6+1	6+1	6+1
Drive System	Model		TZ370XS-LKM0851	TZ370XS-LKM0851	TZ370XS-LKM0851	TZ370XS-LKM0851
	Type		Permanent magnet synchronous motor	Permanent magnet synchronous motor	Permanent magnet synchronous motor	Permanent magnet synchronous motor
	Rated/peak power (kw/rpm)		75/120	75/120	75/120	75/120
	Rated/peak torque (N.m/rpm)		350/850	350/850	350/850	350/850
Power battery	Type		Lithium iron phosphate	Lithium iron phosphate	Lithium iron phosphate	Lithium iron phosphate
	Energy Density Wh/kg		153.84	153.84	153.84	153.84
	Total power storage （kWh）		106.95Ningde	106.95Ningde	106.95Ningde	106.95Ningde
recharge mileage（km)			300 Full load isokinetic method	300 Full load isokinetic method	300 Full load isokinetic method	300 Full load isokinetic method
Special performance	Box material	Q235	○	○	○	○
		Q345	○	○	○	○
		High strength steel	○	○	○	○
	Box volume		5.3 m³	5.8 m³	6.3 m³	7.2 m³
	Case size		5100×2300×450	5600×2300×450	6100×2300×450	7000×2300×450
	Factory standards		Bottom plate 3mm/ side plate 2mm, the overall rear fender is welded to the cargo box, left and right side protection, rear protection, and reverse cursor sticker	Bottom plate 3mm/ side plate 2mm, the overall rear fender is welded to the cargo box, left and right side protection, rear protection, and reverse cursor sticker	Bottom plate 3mm/ side plate 2mm, the overall rear fender is welded to the cargo box, left and right side protection, rear protection, and reverse cursor sticker	Bottom plate 3mm/ side plate 2mm, the overall rear fender is welded to the cargo box, left and right side protection, rear protection, and reverse cursor sticker
Note: Please contact us to confirm the detailed configuration. Customization is supported
