Refrigerated Truck
| Wheelbase | 5800mm-7200mm |
| Engine Model | 4HK1 |
| Engine Horsepower | 205HP-224HP |
| Load | 9T-10T |
| Refrigeration machine brand | Carrier/Thermo King/Domestic |
| Box volume | 47.5 m³-60m³ |
| Box space temperature | ’-18 degrees ~ +20 degrees |
Product Configuration
| Box body | Using polyester wet board making process and fully enclosed polyurethane board bonding method, the thermal insulation performance reaches the national A-level standard. | |||
| Box board | The inner and outer wall panels are made of domestic high-quality nano-glass (non-light-absorbing, good heat insulation, strong hardness, and anti-oxidation), and the middle insulation material is imported polyurethane with no gap filling; the thickness is designed according to the customer's temperature requirements for the box; | |||
| Chassis | The bottom of the box is an aluminum alloy patterned plate or, with a 150mm overall bend skirt, which has better protection and sealing performance; | |||
| Accessories | The perimeter of the box is made of aluminum alloy edging, stainless steel corners, stainless steel door locks, 4 anti-collision rubbers, stainless steel door frames, stainless steel hinges, and energy-saving LED lights in the box. | |||
| Others | The thickness of the box can be selected, and the inner and outer wall panels can be selected from fiberglass, color steel, stainless steel, and aluminum alloy. | |||
| Process quality | The latest fully sealed insulation box, lightweight, high strength, high insulation, and long service life | |||
| Professional customization | Seven years of modification experience, free customization of modification plans according to vehicle needs | |||
| Vehicle advantages | Isuzu refrigerated truck dedicated chassis + high-quality refrigerated compartment + high-quality refrigeration system Perfect match. In the process of refrigerated truck development and design, the chassis, compartment, and refrigeration system are matched and designed according to the whole vehicle thinking, giving full play to the comprehensive performance of high-quality chassis, high-quality refrigerated compartment, and high-quality refrigeration system, not simply patchwork. | |||
Vehicle Diagram
Rain test
Imported insulation board
Pressure plate machine
Process quality
Professional customization
Stainless steel lock
Vehicle Diagram
| Model | Cab Type | WB | OAL | OW | OH | FOH | ROH | L | W | H |
| FTR | Single Row | 5800 | 10000 | 2550 | 4000 | 1335 | 2865 | 7600 | 2400 | 2600 |
| 6300 | 11000 | 2400 | 3500 | 1335 | 3365 | 8600 | 2400 | 2600 | ||
| 7200 | 12000 | 2400 | 3500 | 1335 | 3465 | 9600 | 2400 | 2600 | ||
| Note: Dimensions are for reference and can be customized as needed | ||||||||||
| Isuzu FTR Refrigerated Truck | |||
| Wheelbase | 5800 | 6300 | 7200 |
| Body Volume | 47.5 m³ | 54 m³ | 60 m³ |
| Body Dimensions | 7600×2400×2600 | 8600×2400×2600 | 9600×2400×2600 |
| Refrigeration Brand | Carrier/Thermo King/Domestic | Carrier/Thermo King/Domestic | Carrier/Thermo King/Domestic |
| Body Temperature Range | -18°C ~ +20°C | -18°C ~ +20°C | -18°C ~ +20°C |
| Engine | 205hp/224hp | 205hp/224hp | 205hp/224hp |
| Transmission | Isuzu MLD | Isuzu MLD | Isuzu MLD |
| Product Name | Isuzu FTR Refrigerated Truck | ||||
| Vehicle Parameters | Wheelbase (mm) | 5800 | 6300 | 7200 | |
| Overall Dimensions (mm) | 10000X2550X4000 | 11000X2550X4000 | 12000X2550X4000 | ||
| Gross Weight (Kg) | 18000 | 18000 | 18000 | ||
| Curb Weight (Kg) | 8050 | 8550 | 8960 | ||
| Number of Passengers in Cab | 3 | 3 | 3 | ||
| Maximum Speed | 110 | 110 | 110 | ||
| Tire Specification | 11.00R22.5 16PR | 11.00R22.5 16PR | 11.00R22.5 16PR | ||
| Number of Tires | 6+1 | 6+1 | 6+1 | ||
| Emission Standard | Euro 5, Euro 6 | Euro 5, Euro 6 | Euro 5, Euro 6 | ||
| Transmission Parameters | Transmission Model | Isuzu MLD | Isuzu MLD | Isuzu MLD | |
| Gear Configuration | 6 Forward + 1 Reverse | 6 Forward + 1 Reverse | 6 Forward + 1 Reverse | ||
| 4HK1-TC50 | 151kw/205hp | ○ | ○ | ○ | |
| 4HK1-TCG60 | 151kw/205hp | ○ | ○ | ○ | |
| 4HK1-TCG62 | 164kw/224hp | ○ | ○ | ○ | |
| Special Features | Body Material | Fiberglass + Polyurethane Foam + Fiberglass | Fiberglass + Polyurethane Foam + Fiberglass | Fiberglass + Polyurethane Foam + Fiberglass | |
| Body Volume | 47.5 m³ | 54 m³ | 60 m³ | ||
| Body Dimensions | 7600×2400×2600 | 8600×2400×2600 | 9600×2400×2600 | ||
| Refrigeration Brand | Carrier/Thermo King/Domestic | Carrier/Thermo King/Domestic | Carrier/Thermo King/Domestic | ||
| Body Temperature Range | -18°C ~ +20°C | -18°C ~ +20°C | -18°C ~ +20°C | ||
| Factory Standards | Integrated bending of 150mm skirt edge, 304 stainless steel hardware, side protection, rear protection, body rain test, reflective stickers | Integrated bending of 150mm skirt edge, 304 stainless steel hardware, side protection, rear protection, body rain test, reflective stickers | Integrated bending of 150mm skirt edge, 304 stainless steel hardware, side protection, rear protection, body rain test, reflective stickers | ||
| Remarks: Please contact us for detailed configuration confirmation, customization supported | |||||
